Challenges in excavation work
Exact Depth
During Excavation the driver can only assume the correct depth. To verify the depth needs to be checked manually.
COMPLEX DESIGN
Creating surfaces with multiple slope changes requires even more manual checks.
High operating costs
Manual measurement causes high operating costs and requires a lot of time.
Inclination
The operator can only visually duplicate previous slopes and then manually check them.
Safety
The surveyor who measures the depth manually has to move into a risk zone.
EXPERIENCE
If the operator has not enough experience it will be difficult to get a good result.
Solutions
01
IDEAL IMPLEMENTATION OF SIMPLE EARTHWORKS
Xsite EASY
The 2D system Xsite EASY measures depth, elevation and inclination of the scoop and shows the scoop position graphically and numerically on the display. The upper carriage sensor thereby guarantees correct measurements for every excavator position, whether on a slope or on level ground. An optional LED display additionally shows at a glance whether the target level has already been achieved, or whether further excavation is required. Thereby you always maintain an overview of the exact work progress and you can accurately implement specifications.
Xsite EASY System components
Graphic display
Graphical and numerical display of all working steps during excavator operations.
02
Efficient 2D excavator control for better Dredging results
Xsite PRO 2D
With Xsite PRO you can also benefit from additional features, like up to two GNSS antennas, which determine the position of the excavator via satellite. Thanks to the fast processor, the measured values are processed in real-time and are displayed on the 8.4“ graphic display immediately. The option of defining multiple profiles for different work assignments and having them ready at any time saves time, fuel and material and at the same time increases the efficiency of your machine.
Xsite PRO 2D System components
Operating panel
Rugged 8.4" touch screen display for optimal working experience with Xsite PRO controls.
Controller
Real-time processing of all incoming position data from the connected sensors.
GNSS Compass
Provides important data that is important for the direction of the upper structure and the basis for adjusting the target grade.
03
High-end 3D excavator control for optimal excavation work
Xsite PRO 3D
With Xsite PRO 3D you can also benefit from additional features, like up to two GNSS antennas, which determine the position of the excavator via satellite. Thanks to the fast processor, the measured values are processed in real-time and are displayed on the 8.4“ graphic display immediately. The option of defining multiple profiles for different work assignments and having them ready at any time saves time, fuel and material and at the same time increases the efficiency of your machine.
Xsite PRO 3D System components
Operating panel
Rugged 8.4" touch screen display for optimal working experience with Xsite PRO 3D controls.
Controller
Real-time processing of all incoming position data from the connected sensors.
GNSS Antenna
Precise location in the terrain with GNSS coordinates. This reduces the surveying effort by up to 90% and optimises the user experience.
